US Stock Linear Guide Rail Moduler High Precision 130W/150W/180W CO2 Laser Cutter Laser Engraver with 1300×900mm Workbench and S&A Water Chiller
$8,899.00 – $9,999.00
Linear Guide Rail Module Driving with high precision and free-maitanence multifunctional acrylic wood mdf fabric nonmetallic laser cutting engraving machine is a very popular type machine, this type machine can cut and engrave most nonmetal materials, such as wood acrylic MDF plastic leather plywood etc.
Advantage Features:
- Adopt high-precision linear guide rail drive to make the optical path more stable, cutting and engraving better.Using DSP control system, fast speed, simple operation, high-speed engraving.
- The beam structure is made of high-strength aluminum alloy, which has the advantages of light weight, low resonance and smoother running than traditional steel frame beams.
- Box-type exhaust device to ensure clean working environment
- Very suitable for cutting a whole plate of MDF, acrylic and other materials
Standard Configuration:
- Laser Cutter Machine(Pass Through Doors)
- RECI CO2 Laser Tube
- RUIDA 6445G DSP Software compitable with Lightburn
- Blade Type Workbench 1300×900mm
- Honeycomb Workbench 1300×900mm
- Electric Lifting Workbench
- S&A Water Chiller CW5000/CW5200
- Air Pump
- Exhaust Fan with Pipe
- Focus Lens×1
- Mirrors×3
- Red Dot Pointer
- Auto Focus
- Auto Blowing
- Warning Light
- Open Cover Protection
- Linear Guide Rail Module Driving
Value-Added Options:
- WIFI
- CCD(1.8 Millions Pixels)
- Rotary Axis(TailStock or Rolling Type)
- Air Purifier(4 Layer Filters)
Delivery Notes:
- US Stock and 7 to 15 days delivey time to your door.
| Laser Power & Source | 130W RECI W4, 150W RECI W6, 180W RECI W8 |
|---|
| Product details | |
| Laser Source | RECI W4/W6/W8 |
| Control System | RUIDA 6445G |
| Cooling Way | S&A Water Chiller |
| Cutting Speed | 0-300mm/s |
| Engraving Speed | 0-600mm/s |
| File Format | .plt .dxf .dst .ai .bmp .las. CAD,CoreDraw,etc |
| Laser Power | 130W/150W/180W |
| Workbench Size | 1300×900mm |
| Input Voltage | 220V/110V, 50/60Hz |
