Fiber Laser
$4,299.00 – $6,122.00
This compact tabletop Fiber Laser is furnished with a model LP+ laser source from an industry leading manufacturer, JPT laser.
The machine can be purchased with a 20 watt or more robust 50 watt tube, for deeper and faster engraving.
This Fiber will engrave all metals, anodized aluminum, some leather and leather products. Also plastics such as nylon, ABS, PVC, and PES.
- Laser Source : JPT LP+ 20W or 50W
- Adjustable Frequency Range: 1-600kHz
- Pulse Width: 200ns
- Marking Area Lens: 110*110mm
- Optional/150*150mm/175*175mm
- Rotary Axis Diameter: 100mm
- Software: EZCAD2.0/EZCAD3.0. Support WIN 7/8/10
- Marking speed up to 7m/s; Re-position precision is 0.002mm; Electrical-Optical Conversion: up to 70%.
- Two-Year Warranty. Training video, software included
- Software compatible with CorelDraw, AutoCAD, PLT,PCX,DXF,BMP
- Font support for SHX, TTF fonts. Automatic features for encoding, serializing, batch numbers, date, barcoding, QR coding, consecutive numbering etc.
- Free shipping by DHL/UPS about 7-10 working days.
Warranty and support from our team in the Buffalo, NY office.
Laser Power | 20W, 50W |
---|---|
Lens | 110×110mm, 175×175mm, 220*220mm |
Rotary Axis | Yes, No |
Product details | |
Laser Source | JPT LP E |
Marking Speed | 7m/s |
Laser Power | 20W/30W50W Optional |
Adjustable Frequency Range | 1-600kHz |
Adjustable Pulse Width Range | 200ns |
Lens(Marking Area) | 110×110/150×150/175×175mm |
Engraving Depth | ≤1.0mm |
Min. Character | 0.2mm |
Min. Line Width | 0.01mm |
Output power adjustment range | 10%-100% |
Communication Mode for Automation | TCP/IP, IO,RS232 |
Applicable OS | WIN7/8/10 |
Input Voltage | 110V-240V/50-60Hz |
