200W 300W 500W Pulsed Platform Automatic Laser Cleaning Machine Laser Rust Oil Paint Plating Remover


200W 300W 500W Pulse Type Fiber Laser Cleaner. Three-axis linkage (customizable five-axis) uniform cleaning for removing adhesives or coatings from the surface of objects. For rust paint oil plating removal.

DLC-200 DLC-300 DLC-500 , , , Brand:

Product Parameters:

  • Model: DLC-200 DLC-300 DLC-500
  • Laser power: 200W 300W 500W
  • Laser wavelength: 1064±10nm
  • Operating mode: Pulse
  • Pulse width: 10-500ns
  • Modulation frequency: 1-4000kHz    1-1000kHz
  • Cleaning width:10-750mm(optional field lens:25Amm,330mm,A20mm,width up to 300mm)
  • Workbench size: 1200*1000mm
  • XYZ stroke: 800*300*300mm
  • Input voltage: AC220V±10%
  • Input power: 3kw 3.5kw 5kw
  • Cooling method: Air cooling   Water cooling (Medium: Deionized water, distilled water or purified water)
  • Water tank capacity: 16L (14-15L of water to be added)
  • Main unit size: 1200*1000*1700mm
  • Package size: 1800*1400*1900mm
  • Net weight: 460kg

Features and Advantages:

  • An instantaneous fuse is installed on the output side. Equipment safety is guaranteed.
  • Digital matching cleaning. The laser frequency, galvanometer, and axis speed are matched, high efficiency, no blind spot.
  • Consistent energy with automatic focus control. Stable operation, uniform cleaning and high gloss.
  • Modular design. Stable performance and easy maintenance.
  • 10 safety protection and early warning systems. Automated application, safe and stable.
  • Teching programming easy to operate. Facilitates batch cleaning operations.
  • Intelligent Three-axis Linkage (Customizable five-axis), Flexible and convenient for complex cleaning scenes such as three-dimensional curved surface cleaning.
  • Digital Laser Control. Eight different graphics to choose from to meet complex cleaning conditions.
  • Harsh Tests, Quality Assurance. Heavy dirt, Anti-interference, Vibration , High-temperature, Anti-reflection, Fatigue, Dustroof, High-humidity test.
  • High-speed Galvanometer System. Width up to 300*300mm fast scan speed, uniform energy.
  • Rich I/O Interfaces. Support modbus protocol, easy to connect with other devices.
  • Integrated Thickened Sheet Metal. All-round protection, good heat dissipation.

Application and Service:

  • Digital control of laser parameters ensures no damage to the workpiece and avoids heating and micro-melting. It is suitable for the cleaning of coating, plating, oxidized layers, paint, oil etc. and is especially suitable for the fine cleaning of corrosion-resistant, wear-resistant, and difficult-to-clean materials with high-temperature treatment.
  • The surface of the highly reflective material is not easy to clean, please consult before placing an order. You are welcome to send samples for testing!

Laser Power

300W, 500W, 200W

Product details
Cleaning width 10-750mm
Cooling method Air cooling Water cooling
Input power 3kw 3.5kw 5kw
Input voltage AC220V±10%
Laser power 200W 300W 500W
Laser wavelength 1064±10nm
Main unit size 1200*1000*1700mm
Model DLC-200 DLC-300 DLC-500
Modulation frequency 1-4000kHz 1-1000kHz
Net weight 460kg
Operating mode Pulse
Package size 1800*1400*1900mm
Pulse width 10-500ns
Water tank capacity 16L (14-15L of water to be added)
Workbench size 1200*1000mm
XYZ stroke 800*300*300mm
