300W 500W 1000W Laser Cleaner Technical Parameters:
- Model: BPC-500 BPC-1000
- Laser Power: 500W/1000W Multi Mode(Flat-top beam)
- Laser Wavelength: 1060-1080nm
- Laser Working Mode: Pulsed
- Pulse Width(ns): 10-500; 10-500; 30-500
- Frequency Range:1-1000kHz
- Fiber Cable Length: 10m
- Adjustable Scanning Range: 10-100mm (F254 Len Standard)
- Max single pulse energy: 12mj; 12mj; 15mj
- Cooling Method: Water Cooling
- Working Voltage: AC 220V±10%
- Power Consumption: 3KW/4KW/7KW
- Anti-Reflection Protection: Yes
- Operation Temperature: 0-35°C
- Operation Humidity: ≤80%
- Machine Demension: 1010*600*1010mm/1050*670*1070mm(1000W)
- Net Weight: 160kg/170kg/228kg
SFX High Power Pulse Laser Cleaner Features and Advantages:
- 500w 1000w high power pulse laser cleaning machine. Higher cleaning efficiency. No damage to the substrate. Suitable for rust paint coating fine cleaning.
- Extended IO can cooperate with manipulator, realize automatic cleaning, ensuring consistent and even cleaning results.
- Double wobble smart cleaning head. Enhances stability and ease of operation. Support 8 cleaning modes for complex scenes cleaning.
- SFX 500W 1000W pulse laser cleaning machine equipped with thick sheet metal chassis. Strong structure, anti-deformation and good heat dissipation. 10m fiber cable for larger range of activities.
- All-in-one chassis with hinged top cover. Internal modular design for easy maintenance. Add storage function to protect cables and cleaning head.
- Smart Control Panel. Full touch screen operation interface. Support multilingual process library for easy setup and operation in different languages.
- Passed multiple rigorous tests ( High temperature/Vibration/Anti-interference/Fatigue/High humidity/Bend resistance test), Ensures reliable, stable, and durable performance.
SFX 500W 1000W Pulse Laser Cleaner Application and Service:
- SFX 500w 1000w pulse laser cleaning machine is suitable for rust, oil, paint, coating, mold cleaning, adhesive layer removal, cultural relic restoration, etc.
- Can be used in aerospace, mold, automobile, food, tire hub, pharmaceutical, chemical, military manufacturing and other industries.
- 1 Year warranty for the whole machine, 2 Years warranty for the laser source. (Consumables are not covered by warranty)
- After sales center in NY, US. Offer remote assistance for after-sales issues, lifetime online technical support.
- Free shipping to your door by DHL about 5-10 days, No import duty for American customers. 1000w pulse laser cleaning machine production time is 20 days.
- SFX laser cleaning machine was well reviewed by many of our customers. SFX Laser Cleaning Machine Customers Feedback
Application Scene Comparison Between Single Mode pulse laser cleaner and Multi Mode pulse laser cleaner:
Single Mode Laser Cleaner（Gaussian Beam）: Suitable for strong adhesion cleaning such as Heavy rust, Oxide Layer, Thick paint, Galvanized layer removal and Stone, Wood, Plastic painting coating Cleaning.
Multi Mode Laser Cleaner（Flat-top Beam）: Suitable for light adhesion cleaning such as Thin rust on metal surface removal, automobile paint removal, mold cleaning, no damge to substrate.
Note: Due to product updates, there may be differences in appearance and parameters. Please refer to the latest actual product.
